Lightweight design, Lightweight and quick unloading speed
Adopting advanced foreign technology, the vacuum degree maintains a long time. The outer surface is painted with imported paint and maintained for life
Structural optimization design, with fast oil unloading, low liquid storage capacity, and improved economic efficiency.
Standard-equipped vehicle lifting system for cleaner unloading.
Standard vehicle lifting system for cleaner unloading
Standard equipped with WABCO / KNORR EBS with brake pad wear alarm system.and improve the safety during transportation
| filling medium | Tank Material | Design pressure MPA |
Design Temperature ℃ |
geometric volume m³ |
Vehicle GVWR kg |
Maximum loading capacity kg |
Gross weight kg |
saddle height mm |
Overall dimensions mm |
Tractor suggested to use | wheelbase |
| liquid nitrogen | Inner S30408/S30458 outer Q345R | 1.6 inner/-0.1 outer | -143 inner/50 outer | 35.8 | 13,700 | 26,300 | 40,000 | 1240 | 12770x2500x3600 | 6×4 quasi-traction mass ≥ 40 ton | 6435+1310+1310 |
