Lightweight design, Lightweight and quick unloading speed
Adopting advanced foreign technology, the vacuum degree maintains a long time. The outer surface is painted with imported paint and maintained for life
Structural optimization design, with fast oil unloading, low liquid storage capacity, and improved economic efficiency.
Standard-equipped vehicle lifting system for cleaner unloading.
Standard vehicle lifting system for cleaner unloading
Standard-equipped WABCO EBS with brake pad wear alarm system.
| filling medium | Tank Material | Design pressure MPA |
Design Temperature ℃ |
geometric volume m³ |
Vehicle GVWR kg |
Maximum loading capacity kg |
Gross weight kg |
saddle height/ Mass of saddle |
Overall dimensions mm |
Tractor suggested to use |
| liquid oxygen | Inner S30408/S30458 outer Q345R | 1.13/–0.07 1.45/-0.07 |
－ 196 | 26 | 12,800 | 27,200 | 40,000 | 1240/16000 | 11550, 11750x2500x3340 | 6×4 quasi-traction mass ≥ 40 ton |
